توضیحات

مشخصات:

Dial size: 63 mm, 80 mm, 100 mm, 160 mm

Unit scale: °C, °F, °C/°F (dual scale)

Case filling: With (silicone oil), Without

Window: Polycarbonate, safety laminated glass, instrument glass

Case & bezel ring material: S.S 304, S.S 316

Stem & socket material: S.S 316

Connection location: Bottom connection, Center back connection

Connections: G ½ B male, ½ NPT male, G ½ B female, ½ NPT female, M20 x 1.5, M24 x 1.5 female

Connection designs: Threaded connection, Sliding union

Stem diameter: 6 mm, 8 mm

Versions: Standard version, Oil- and grease-free version, Silicone-oil-less version

Ingress protection: IP65, IP66, IP67

According to EN-13190 standard
