مشخصات:

Dial size: 160 mm

Accuracy: ±0.6% of F.S

Unit: mbar, psi, kg/cm², Pa, kPa, mmH2O, inH2O, oz/in2 (Single or Dual scale)

Case material: S.S 304

All wetted parts material: S.S 316 L

Connection size: G 1/2 B, M 12×1.5, M 20×1.5, 1/2″ NPTM

Connection location: Bottom connection, lower back connection

Mounting: without (Direct mounting), Front flange (Panel mounting), Back flange (Surface mounting)

Glass: Laminated safety glass

Special feature: Oil- and grease-free, Oil- and grease-free for Oxygen

Restrictor: Without, 0.6 mm, 0.3 mm

Ingress protection: IP54

According to EN837-3
