مشخصات:

Dial size: 100 mm, 160 mm

Case filling: With (glycerin oil, silicone oil), Without

Case material: S.S 316, S.S 316 L

Wetted parts material: S.S 316 L,  Hastelloy C-276, Inconel

Unit scale: bar, psi, kPa, MPa, kg/cm² (Dual or Single unit), mmH2O, inH2O

Process connections: 2*G1/2 B Male, 2*G1/2 Female, 1/2″ NPTM

Connection location: Lower mount (Radial)

Features: Blow out disc

Special design features: Oil & grease free, Oil & grease free for Oxygen, Silicone free,

NACE MR 0175

Window: Laminated safety glass

Ingress protection: IP54, IP65, IP66

Restrictor: Without, 0.6 mm Stainless steel, 0.3 mm Stainless steel

According to EN837-3 standard
