مشخصات:

• Temperature Range:
  • RTDs: -200°C to +850°C.
  • Thermocouples: -200°C to +1800°C.
• Accuracy: ±0.1% of span (±0.05% for high-precision models).
• Output Signal: 4-20 mA, 2-wire (HART, Profibus optional).
• Power Supply: 10…30 V DC.
• Sensor Compatibility: RTDs (Pt100, Pt1000), thermocouples (J, K, T, E, etc.).
• Housing Material: Stainless steel (316L), aluminum, or plastic.
• Operating Temperature: -40°C to +85°C.
• IP Rating: IP65/IP66/IP67.
• Response Time: <1 second.
• Certifications: ATEX, IECEx.
• Weight: 0.2–1.5 kg.

Customizable Options:

• Sensor type, output protocol, display, mounting brackets.
